BSS 7230 Aircraft Interior Material Flammability Tester

A multifunctional combustion test chamber approved by the FAA (Federal Aviation Administration). It is capable of performing vertical, horizontal, 45°, and 60° flammability tests for insulation wires. The system allows rapid switching between different test configurations for user convenience. The chamber complies not only with FAA flammability testing standards but also with domestic civil aviation standards such as HB5469 and HB5470.

Application

Aviation

Standards

BSS: BSS 7230 F1, F2, F3, F4, F5, F6

AITM: AITM 2.0005, AITM 2.0004, AITM 2.0002, AITM 2.0002A

FAA: FAR Part 25 Appendix F Part I (a)(3), (a)(2)(iii), (a)(1)(v), (a)(1)(iv), (a)(1)(ii), (a)(1)(i)

Parameters

Dimensions: 1200 mm (W) × 1150 mm (H) × 750 mm (D)

Weight: 52 kg

Installation Requirements

Power supply: 220 V, 5 A

Ambient temperature: 10°C to 35°C

Combustion gas: Propane

Features

(1) Stainless steel inner chamber with electrostatic powder-coated exterior

(2) Large heat-resistant glass observation window for easy monitoring

(3) Equipped with gas pressure and flow regulation devices

(4) Bunsen burner mounted on a sliding rail for convenient operation

(5) Electric spark ignition system for easy ignition

(6) Stainless steel specimen holder and weight for 60° burn test

(7) Flame height gauge for accurate measurement

(8) Specimen positioning tool to ensure correct distance from burner

FAQ

(1) What is this product?

It is a multifunctional flammability tester designed to evaluate fire performance of aircraft interior materials under controlled combustion conditions following aviation standards.

(2) What is this product used for?

It is used for testing flammability characteristics of aviation materials such as insulation, wiring, and interior components to ensure compliance with safety regulations.

(3) What is the working principle of this product?

The tester applies a controlled flame to a specimen under defined angles and conditions, measuring burning behavior such as flame spread, after-flame time, and material damage.

(4) Why is this product important?

It is critical for ensuring aircraft fire safety by verifying that interior materials meet strict flammability standards, reducing fire risk during operation.

(5) What industries is this product suitable for?

It is mainly used in the aviation industry, including aircraft manufacturers, material suppliers, certification laboratories, and research institutions.
