Dummy for Wheelchair Vehicle Testing
The Dummy for Wheelchair Vehicle Testing is designed to simulate the physical characteristics and mass distribution of a human occupant during wheelchair transport. It is used to evaluate the performance of wheelchair restraint systems and vehicle safety under dynamic conditions. Manufactured in accordance with ISO 7176-11:2012 and GB/T 12996-2024 standards, it ensures consistent, repeatable, and reliable test results for safety verification and compliance assessment.
Compliance Standards:
The test dummy meets the requirements of:
European Standard: ISO 7176-11:2012
New Chinese Standard: GB/T 12996-2024
Total Mass of the Dummy: 100 kg
Articulation Features:
The lower legs of the dummy can move up, down, left, and right.
The footplate joints are movable.
ISO 7176-11 Standard Reference Table：
Reference Number Explanation:
1 — Rear
2 — Upper surface
Radius tolerance: ±5 mm
Unit: millimeters
Table 2: Dimensions of Thigh Loading Plate
Manikin Weight Range Kg | L1 mm | L2 mm | L3 mm | L4 mm |
25≤mdummy＜50 | 200 | 300 | 80 | 150 |
50≤mdummy＜75 | 260 | 350 | 100 | 175 |
75≤mdummy＜100 | 320 | 380 | 105 | 160 |
100≤mdummy＜125 | 380 | 420 | 110 | 135 |
125≤mdummy＜150 | 430 | 440 | 115 | 110 |
150≤mdummy＜175 | 480 | 440 | 120 | 100 |
175≤mdummy＜200 | 530 | 440 | 120 | 100 |
200≤mdummy＜250 | 570 | 440 | 120 | 100 |
250≤mdummy＜300 | 630 | 440 | 120 | 100 |
mdummy≥300 | 680 | 440 | 120 | 100 |
Tolerances for all linear dimensions: ±15 mm. Note: Dimensions are based on typical wheelchair seat sizes used for occupants within the specified weight ranges. | ||||
Reference Number Description:
1 — Upper edge
2 — Front
Radius tolerance: ±5 mm
Reference Number Description:
1 — Side
2 — Top
Radius tolerance: ±5 mm
Table 3: Dimensions of Torso and Foot Loading Plates
Manikin Weight Range Kg | Torso Loading Plate | Foot Loading Plate | ||
L1 mm | L2 mm | L3 mm | L4 mm | |
25≤mdummy＜50 | 180 | 380 | 80 | 200 |
50≤mdummy＜75 | 230 | 440 | 100 | 300 |
75≤mdummy＜100 | 290 | 490 | 100 | 300 |
100≤mdummy＜125 | 350 | 540 | 100 | 300 |
125≤mdummy＜150 | 400 | 540 | 100 | 300 |
150≤mdummy＜175 | 450 | 540 | 100 | 300 |
175≤mdummy＜200 | 500 | 540 | 100 | 300 |
200≤mdummy＜250 | 540 | 540 | 100 | 300 |
250≤mdummy＜300 | 600 | 540 | 100 | 300 |
mdummy≥300 | 650 | 540 | 100 | 300 |
Tolerances for all linear dimensions: ±15 mm. Note: Dimensions are based on typical wheelchair seat sizes used for occupants within the specified weight ranges. | ||||
FAQ
1.What is this product?
This product is a dummy designed for wheelchair vehicle testing, used to simulate a human occupant during transportation.
2.What is this product used for?
It is used to evaluate the performance of wheelchair restraint systems and vehicle safety under test conditions.
3.What is the working principle of this product?
It simulates human mass distribution and articulation to reproduce real occupant behavior during testing.
4.Why is this product important?
It ensures accurate, consistent, and repeatable test results for safety verification and standard compliance.
5.What industries is this product suitable for?
It is suitable for automotive testing, wheelchair manufacturing, mobility equipment, and safety research industries.
6.Is the dummy compliant with relevant testing standards?
We design our Dummy for Wheelchair Vehicle Testing to be compatible with widely recognized standards such as ISO 10542, ISO 7176-19, and SAE J2249. We ensure the dummy can be integrated into standard test setups to support compliant and reliable safety evaluations.
7.What occupant size and weight does the dummy simulate?
We offer Wheelchair Testing Dummy options that simulate realistic human body dimensions, including adult and pediatric configurations. We carefully design weight distribution and posture to reflect actual wheelchair users, helping you obtain meaningful and consistent test results.
8.Can the dummy be equipped with sensors or instrumentation?
We provide Wheelchair Crash Test Dummy configurations that support instrumentation such as accelerometers and load sensors. We can customize the setup based on your testing requirements to help you capture accurate data for analysis and product development.
9.Is the dummy compatible with different wheelchair types and test setups?
We design our Wheelchair Vehicle Testing Dummy to be compatible with various wheelchair types, including manual and powered models. We ensure it can be used with different tie-down and restraint systems to support a wide range of testing applications.
10.How durable is the dummy for repeated testing?
We manufacture our Wheelchair Test Dummy using durable materials to support repeated testing scenarios. We focus on structural reliability to help maintain consistent performance over multiple test cycles, reducing downtime and improving testing efficiency.
