Gelbo Flex Resistance Tester

Gelbo Flex flexing chamberTest principle:

The sample in the test chamber experiences a comprehensive effect of torsion and compression. During the process of torsion, the air is drawn from the chamber and the particles in the air are counted and classified using a laser dust particle counter.

Gelbo Flex Tester Standards:

YY/T 5056.6  Surgical drapes, gowns and clean air suits, used as medical devices for patients, clinical staff and equipment - Part 4: Dry lint test methods.
ISO 9073.10 Textiles. Test methods for nonwovens. Part 10_Lint and other particles generation in the dry state.
EN 13795-2-2004 Surgical drapes, gowns and clean air suits, used as medical devices for patients, clinical staff and equipment - Part 2 Test methods.


Gelbo Flex Tester with Particle Counter Principle:

The sample is subjected to a combined effect of torsion and compression in the test chamber. During this twist, air is drawn from the chamber and the particles in the air are counted and classified by using a laser dust particle counter.


Product parameters:

1, sealed torsion room and Air manual machine;

2, twist speed: 60 times / minute

3, twist angle / stroke: 180 ° / 120mm

4, sample fixture: 82.8mm

5, laser particle counter test range: collection of 0.3-25.0um samples

6, laser particle counter flow rate: 28.3L / min, ± 5%

7, sample test data storage: 3000

8, timer: 1-9999 times
