Geotextile Thinkness Tester, to determine the thickness of geotextile synthetic materials and related products under pressure and in specified time.
Application:
Geotextile Thinkness Tester, to determine the thickness of geotextile synthetic materials and related products under pressure and in specified time.
standards:
ISO9863, ASTM D5199, JTG E50 T1112, SL/T235, GB/T13761, etc.
Specifications:
Area of presser foot: 25 sq. cm
Weight of presser foot: 5N (Self-weight: 510.2g, 4 pieces)
Sample pressure: 2±0.01kpa / 20±0.1kPa / 200±0.1kPa
Dial indicdator: 0~24±0.01mm
Micrometer gauge: 0~1±0.001mm
Stopwatch: resolution 0.1s
Test Method:
Test specimens are taken from various locations across the full width of the sample geotextile, The specimens are placed on a flat planar surface. A circular presser foot is lowered onto the geotextile for a pre-determined time. The nominal thickness of each geotextile is then recorded and the sum total averaged to determine the mean thickness under the prescribed pressure.
Technical Parameters:
Weight:40 kg
Width: 730 mm
Depth: 320 mm
Height:350 mm
Features:
1、High precision dial gauge;
2、High precision pressurized weights, the use of leverage, provide multiple levels of pressure;
3、Has a bubble level to ensure that the instrument level;
4、Special surface treatment, anti-corrosion;
5、Widely in line with domestic and international standards;
6、Principle is simple, easy to operate;
